PROCESSOR | Supports 12th Gen Intel® Core™, Pentium® Gold and Celeron® Processors Processor socket LGA1700 |
CHIPSET | Intel® Z690 Chipset |
MEMORY | 4x DDR5 memory slots, support up to 128GB1 Supports 1R 4800 MHz (by JEDEC & POR) Max. overclocking frequency:
Supports Dual Controller Dual-Channel mode Supports non-ECC, un-buffered memory |
EXPANSION SLOTS | 3x PCIe x16 slots
|
ONBOARD GRAPHICS | 1x HDMI 2.1 with HDR port, supports a maximum resolution of 4K 60Hz 1x DisplayPort 1.4 port with HBR3, supports a maximum resolution of 4K 60Hz |
MULTI-GPU | Supports AMD® CrossFire™ Technology |
STORAGE | 4x SATA 6Gb/s ports - SATA5~8* (From Z690 Chipset)[1] 2 x SATA 6Gb/s ports - SATAA & SATAB (From ASMedia ASM1061) 5x M.2 slots (Key M)
[1] SATA7 will be unavailable when installing M.2 SATA SSD in the M2_4 slot. |
RAID | Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices Supports RAID 0, RAID 1 , RAID 5 and RAID 10 for M.2 NVMe storage devices |
USB | Intel® Z690 Chipset
|
AUDIO | Realtek® ALC4080 Codec
|
LAN | 1x Intel® I225V 2.5Gbps LAN controller |
WIFI & BLUETOOTH | Intel® Wi-Fi 6E module
[2] Bluetooth 5.2 will be ready in Windows 10 build 21H1 and Windows 11. |
INTERNAL CONNECTORS | 1x 24-pin ATX main power connector 2x 8-pin ATX 12V power connectors 6x SATA 6Gb/s connectors 5x M.2 slots (M-Key) 1x USB 3.2 Gen 2 10Gbps Type-C connector 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports) 2x USB 2.0 Type-A connectors (supports additional 4 USB 2.0 ports) 1x 4-pin CPU fan connector 1x 4-pin water-pump fan connector 6x 4-pin system fan connectors 1x Front panel audio connector 2x System panel connectors 1x Chassis Intrusion connector 1x Clear CMOS jumper 1x TPM module connector 1x TBT connector (supports RTD3) 1x Tuning Controller connector |
LED FEATURE | 1x EZ LED Control switch 4x EZ Debug LED 1x 2-Digit Debug Code LED 1x 4-pin RGB LED connector 2x 3-pin RAINBOW LED connectors 1x 3-pin CORSAIR LED connector |
BACK PANEL PORTS | USB 2.0 DisplayPort 2.5G LAN Wi-Fi/Bluetooth Audio Connectors Flash BIOS Button HDMI USB 3.2 Gen 2 10Gbps Type-A USB 3.2 Gen 2x2 20Gbps Type-C Optical S/PDIF Out |
DIMENSIONS | ATX Form Factor 12 in. x 9.6 in. (30.5 cm x 24.4 cm) |
OPERATING SYSTEM | Support for Windows® 11 64-bit, Windows® 10 64-bit |
Thay Mainboard Msi Mpg Z690 Force Wifi Ddr5 Mới Chính Hãng Có Bảo Hành
Cung Cấp Và Thay Linh Kiện Mainboard Msi Mpg Z690 Force Wifi Ddr5
Bán Mainboard Msi Mpg Z690 Force Wifi Ddr5 Chính Hãng Có Bảo Hành
Chào Mừng Quý Khách Đến Với Trung Tâm Bảo Hành Mainboard Msi Mpg Z690 Force Wifi Ddr5
Tư Vấn Bảo Hành Cung Cấp 24/7: 028.3844.2008
Kính Chào Quý Khách!
Trung Tâm Bảo Hành Mainboard Msi Mpg Z690 Force Wifi Ddr5 Trên Toàn Quốc , Phục Vụ Cả Ngày Lễ Và Chủ Nhật Không Nghỉ Trua 7h30-20h30
Bạn Lăn Tăn Mua Trả Góp 0% Mainboard Msi Mpg Z690 Force Wifi Ddr5 Ở Đâu? Làm Sao Để Thuê Được Giá Rẻ? Cùng Vienmaytinh Tìm Hiểu Về Vấn Đề Này Nhé.
- Bạn Có Nhu Cầu Dùng Mainboard Msi Mpg Z690 Force Wifi Ddr5 Ngay Bây Giờ
- Bạn Đang Lăn Tăn Thay Linh Kiện Giá Mắc Lại Còn Bệnh Vặt Phải Nhờ Người Quen Biết Để Giải Quyết Nhanh Làm Sao Có Ngay Dùng Liền Nếu Phù Hợp Với Bạn... Sau Đó Mới Mua
- Bạn Muốn Trải Nghiệm Dịch Vụ Cho Thuê Mainboard Msi Mpg Z690 Force Wifi Ddr5 Học Cách Làm Mới Tiết Kiệm Tg Chi Phí
- Bạn Muốn Sử Dụng Mainboard Msi Mpg Z690 Force Wifi Ddr5 , Điện Thoại Laptop Surface Trong Thời Gian Ngắn Hạn.....
Chính Vì Vậy:
Vienmaytinh Cung Cấp Dịch Vụ Bán Trả Góp 0% , Cho Thuê Mainboard Msi Mpg Z690 Force Wifi Ddr5 - Thuê Vip Với Nhiều Phương Án Linh Hoạt!
Phương Châm: Dùng Bao Nhiêu Trả Bấy Nhiêu - Hợp Mua - Giải Quyết Công Việc Trước Mắt Đã.
Gọi Ngay Cho Mr Minh - 0903 613 753 - 1800 1080 Để Tìm Hiểu Và Lựa Chọn Dịch Vụ Thuê Hợp Với Bạn.
